Intel 21555 User Manual

128 21555 Non-Transparent PCI-to-PCI Bridge User Manual
List of Registers
057:054
I2O Outbound Post_List Head Pointer,
page 167
I20 Outbound Post Head Pointer
Indeterminate Y Y
05B:058
I2O Inbound Post_List Counter, page 168
I20 Inbound Post Counter
00000000 Secondary Y
05F:05C
I2O Inbound Free_List Counter, page 168
I20 Inbound Free Counter
00000000 Secondary Y
063:060
I2O Outbound Post_List Counter, page 169
I20 Outbound Post Counter
00000000 Secondary Y
067:064
I2O Outbound Post_List Counter, page 169
I20 Outbound Free Counter
00000000 Secondary Y
06B:068
Downstream Memory 0, 2, 3, and Upstream
Memory 1 Translated Base Register, page
137
Downstream Memory 0 Translated Base
Indeterminate Y Y
06F:06C
Downstream I/O or Memory 1 and
Upstream I/O or Memory 0 Translated Base
Register, page 136
Downstream I/O or Memory 1 Translated
Base
Indeterminate Y Y
073:070 Downstream Memory 0, 2, 3, and Upstream
Memory 1 Translated Base Register, page
137
Downstream Memory 2 Translated Base
Downstream Memory 3 Translated Base
Indeterminate Y Y
077:074 Indeterminate Y Y
07B:078
Downstream I/O or Memory 1 and
Upstream I/O or Memory 0 Translated Base
Register, page 136
Upstream I/O or Memory 0 Translated Base
Indeterminate Y Y
07F:07C
Downstream Memory 0, 2, 3, and Upstream
Memory 1 Translated Base Register, page
137
Upstream Memory 1 Translated Base
Indeterminate Y Y
083:082
Chip Status CSR, page 170
Chip Status CSR
0000 W1TC Y
085:084
Chip Set IRQ Mask Register, page 170
Chip Set IRQ Mask
FFFF W1TS Y
087:086
Chip Clear IRQ Mask Register, page 171
Chip Clear IRQ Mask
FFFF W1TC Y
08B:088
Upstream Page Boundary IRQ 0 Register,
page 171
Upstream Page Boundary IRQ 0
00000000 W1TC Y
08F:08C
Upstream Page Boundary IRQ 1 Register,
page 172
Upstream Page Boundary IRQ 1
00000000 W1TC Y
Table 33. CSR Address Map (Sheet 3 of 5)
Byte
Offset
(Hex)
Register Name Reset Value Write Access Read Access
