This is a standard PCI configuration register which defines which interrupt request line on the
interrupt controller this function’s interrupt pin (see register 3DH) is connected to. The power-up
default value is FFh.
8.1.15 Interrupt Pin
Address Offset: 3Dh Size: 8 bits
Default Value: 01h Attribute: Read Only
This is a standard PCI configuration register which defines which of the four PCI interrupt pins,
INTA# through INTD#, this function is connected to. PCI Hot-Plug is connected to INTA#, making
this value hard-wired to 01h.
8.1.16 Hot-Plug Slot Identifier
Address Offset: 40h-41h Size: 16 bits
Default Value: 0000h Attribute: Partial Read/Write
This register indicates which slots support hot-plug. Not used by the IHPC, this register is set by
the boot ROM for later reference by the hot-plug drivers. This register is also mapped to memory
space. System designers are required to follow a convention whereby hot-plug slots are always
implemented in sequential PCI device number order. IHPC slot A should be the lowest numbered
slot (i.e. the device number in this register).
Bits
Description
15:8 reserved(0)
7:4 The PCI device number for the first slot that supports hot-plug.
3:0 Number of hot-plug slots controlled.
8.1.17 Miscellaneous Hot-Plug Configuration
Address Offset: 42h-43h Size: 16 bits
Default Value: 0002h
1
Attribute: Read/Write, Write-Once, Read-Only
This is a hot-plug specific register used to configure many features of the IHPC.
Bits
Description
15 Change device ID. Write Once/Read Only. Changes the device ID from 123Fh to 123Eh
in order to “hide” the IHPC from industry-standard hot-plug drivers and device
enumerators in non-hot-plug systems.
14 Inhibit hot-plug registers. Write Once/Read Only. This bit prohibits access to the IHPC
registers, effectively disabling the IHPC.
13 Enable Power Fault functions. This bit must be set to enable other power-fault related
SERR signaling.
12 Enable Lock of the Auto Power-Down Disable bit. Write Once/Read Only. This bit
should be written to a logic 1 (by firmware) after the Auto-Power-Down Disable bit of
the Hot-Plug Miscellaneous register has been written. Once written, this bit causes the
Auto-Power-Down Disable bit to be unchangeable until XRST# or PCI reset. This
prevents driver software from changing the auto-power-down feature.
1. Bit 0 may be changed to a 1 after Reset in future implementation.
