Intel Desktop Board D865GVHZ Technical Product Specification
66
#
INTEGRATOR’S NOTES
• Use only ATX12V-, SFX12V-, or TFX12V-compliant power supplies with the Desktop Board
D865GVHZ. ATX12V, SFX12V, and TFX12V power supplies have an additional power lead
that provides required supplemental power for the processor. Always connect the 20-pin and
4-pin leads of ATX12V, SFX12V, and TFX12V power supplies to the corresponding connectors
on the desktop board, otherwise the board will not boot.
• Do not use a standard ATX power supply. The board will not boot with a standard ATX power
supply.
Table 30. ATX12V Power Connector
Pin Signal Name Pin Signal Name
1 Ground 2 Ground
3 +12 V 4 +12 V
Table 31. Processor Fan Connector
Pin Signal Name
1 Control (optional)
2 +12 V
3 CPU_FAN_TACH
Table 32. Main Power Connector
Pin Signal Name Pin Signal Name
1 +3.3 V 11 +3.3 V
2 +3.3 V 12 -12 V
3 Ground 13 Ground
4 +5 V 14 PS-ON# (power supply remote on/off)
5 Ground 15 Ground
6 +5 V 16 Ground
7 Ground 17 Ground
8 PWRGD (Power Good) 18 No connect
9 +5 V (Standby) 19 +5 V
10 +12 V 20 +5 V
