1.4 Graphics Capabilities

The kit supports graphics computing through AMD Radeon™ 540X

1.4.1 AMD Radeon™ 540X Graphics

The AMD Radeon graphics controller features the following:

 Supports HDR-10 video playback.

 Multi View Coding (MVC) support for Blu-ray 3D content.

 3D graphics hardware acceleration supporting DirectX 12, OpenCL* 2.0, OpenGL 4.5

 Dedicated Unified Video Decoder hardware (UVD) for H.264, HEVC, VC-1, MPEG-4, MPEG-

2, and MVC decode

 Non-HBR compressed audio pass-through up to 6.144 Mbps, support AC-3, MPEG1, MP3

(MPEG1 layer 3), MPEG2, AAC, DTS, ATRAC, Dolby Digital+, WMA Pro, and DTS-HD

 HBR compressed audio pass-through up to 24.576 Mbps, support DTS-HD Master Audio

and Dolby True HD.

 Supports content protection using High-Bandwidth Digital Content Protection (HDCP) 2.2

 Support only GDDR5 DRAM.

 Supports AMD FreeSync™ technology

1.4.2 High Definition Multimedia Interface* (HDMI*)

The HDMI ports are compliant with the HDMI 2.0b specification. The HDMI ports support

standard, enhanced, or high definition video, plus multi-channel digital audio on a single cable.

The maximum supported resolution is 4096 x 2160 @ 60 Hz, 36bpp.

1.4.2.1 Integrated Audio Provided by the HDMI Interfaces

The following audio technologies are supported by the HDMI 2.0b interfaces directly from

the SoC:

• AC3 - Dolby* Digital

• Dolby®-TrueHD Bitstream Capable

For information about

Refer to

HDMI technology

http://www.hdmi.org

1.4.3 Mini DisplayPort* (mDP*)

DisplayPort is a digital communication interface that utilizes differential signaling to achieve a

high bandwidth bus interface designed to support connections between PCs and monitors,

projectors, and TV displays. DisplayPort is suitable for display connections between consumer

electronics devices such as high definition optical disc players, set top boxes, and TV displays.

The maximum supported resolution is 7680 x 4320 @ 30Hz, 24bpp. DisplayPort via mini

Display Port connector is compliant with the DisplayPort 1.4 specification.

DisplayPort output supports Multi-Stream Transport (MST) which allows for multiple

independent video streams (daisy-chain connection with multiple monitors) over a single

Intel NUC8i5INH User Manual
