Intel NUC8i5INH User Manual

Technical Reference
41
Table 10 lists the connectors and headers identified in Figure 12.
Table 10. Connectors and Headers Shown in Figure 12
Item from
Figure 12
Description
A
SDXC slot
B, C
Front panel single-port USB 2.0 header (USB1/USB2) (1.25 mm
pitch)
D
M.2 connector
E
SATA 6.0 Gb/s connector
F
BIOS security jumper (BIOS_SEC)
G
RTC Battery connector
H
Consumer Electronics Control (CEC) connector (1.25 mm pitch)
Signal Tables for the Connectors and Headers
Table 11. SATA Power Header (0.5 mm Pitch)
Pin
Signal Name
1, 2, 3, 4
5 V
5
Null
6, 7
3.3 V
8
Null
9, 10
GND
11
Rx Data(Positive)
12
Rx Data(Negative)
13
GND
14
Tx Data(Negative)
15
Tx Data(Positive)
16, 17, 18,
19, 20
GND
