Intel NUC8i5INH User Manual

Product Description
27
1.10 Hardware Management Subsystem
The hardware management features enable the board to be compatible with the Wired for
Management (WfM) specification. The board has several hardware management features,
including thermal and voltage monitoring.
For information about
Refer to
Wired for Management (WfM) Specification
www.intel.com/design/archives/wfm/
1.10.1 Hardware Monitoring
The hardware monitoring and fan control subsystem is based on an ITE IT8987VG embedded
controller, which supports the following:
 Processor and system ambient temperature monitoring
 Chassis fan speed monitoring
 Voltage monitoring of DC Input Voltage, Memory Voltage Input, Processor Input Voltage,
GPU Core Voltage.
 SMBus interface
1.10.2 Fan Monitoring
Fan monitoring can be implemented using third-party software.
