Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSConnector/Header Locations and Pin-outs
Revision 1.1 93
Intel order number G34153-003
6.3.2 Multiport Mini-SAS/SATA Connectors
The board includes two 40-pin high density multiport mini-SAS/SATA connectors. On the board,
these connectors are labeled as “SCU0 port(0-3)” supporting the chipset embedded SCU0
controller, and “SCU1 Port(4-7)”, supporting the embedded SCU1 controller. Both connectors
can support up to four SATA or SAS ports each. By default, only the connector labeled “SCU0
Port(0-3)” is enabled and has support for up to four SATA ports capable. The connector labeled
“SCU1 Port(4-7)” is only enabled when an optional 8-port SAS or SATA Intel
®
RAID C600
Upgrade Key is installed. The following tables provide the pin-out for each connector.
Table 37. Multiport SAS/SATA Connector Pin-out ("SCU_0 (0-3)")
Table 38. Multiport SAS/SATA Connector Pin-out ("SCU_1 (4-7)")
