System Event Log Troubleshooting Guide for EPSD
Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 17
Power Supply 2 Temperature
(PS2 Temperature)
Power Supply Temperature
Sensors
Table 27: Power Supply Temperature Sensor – Event Trigger Offset – Next
Steps
Hard Disk Drive 15 – 23 Status
(HDD 15 – 23 Status)
Hard Disk Drive Monitoring
Sensor
Table 90: Hard Disk Drive Monitoring Sensor - Event Trigger Offset – Next
Steps
Hot-Swap Controller 1-3 Status
(HSC1 – 3 Status)
Hot-Swap Controller Health
Sensor
HSC Health Sensor – Next Steps
Processor 1 Status
(P1 Status)
Table 48: Processor Status Sensors – Next Steps
Processor 2 Status
(P2 Status)
Table 48: Processor Status Sensors – Next Steps
Processor 3 Status
(P3 Status)
Table 48: Processor Status Sensors – Next Steps
Processor 4 Status
(P4 Status)
Table 48: Processor Status Sensors – Next Steps
Processor 1 Thermal Margin
(P1 Therm Margin)
Table 40: Thermal Margin Sensors – Next Steps
Processor 2 Thermal Margin
(P2 Therm Margin)
Table 40: Thermal Margin Sensors – Next Steps
Processor 3 Thermal Margin
(P3 Therm Margin)
Table 40: Thermal Margin Sensors – Next Steps
Processor 4 Thermal Margin
(P4 Therm Margin)
Table 40: Thermal Margin Sensors – Next Steps
Processor 1 – 3 Thermal Control %
(P1 – P4 Therm Ctrl %)
Processor Thermal Control
Sensors
Processor Thermal Control % Sensors – Next Steps
Processor 1 ERR2 Timeout
(P1 ERR2)
Processor ERR2 Timeout Sensor
Processor ERR2 Timeout – Next Steps
Processor 2 ERR2 Timeout
(P2 ERR2)
Processor ERR2 Timeout Sensor
Processor ERR2 Timeout – Next Steps
