Intel S2600GZ User Manual

Sensor Cross Reference List
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
18 Intel order number G90620-002 Revision 1.1
Sensor
Number
Sensor Name
Details Section
Next Steps
7Eh
Processor 3 ERR2 Timeout
(P3 ERR2)
Processor ERR2 Timeout Sensor
Processor ERR2 Timeout – Next Steps
7Fh
Processor 4 ERR2 Timeout
(P4 ERR2)
Processor ERR2 Timeout Sensor
Processor ERR2 Timeout – Next Steps
80h
Catastrophic Error
(CATERR)
Catastrophic Error Sensor
Table 50: Catastrophic Error Sensor – Event Data 2 Values – Next Steps
81h
Processor 1 MSID Mismatch
(P1 MSID Mismatch)
Processor MSID Mismatch
Sensor
Processor MSID Mismatch Sensor – Next Steps
82h
Processor Population Fault
(CPU Missing)
CPU Missing Sensor
CPU Missing Sensor – Next Steps
83h-86h
Processor 1 – 4 DTS Thermal
Margin
(P1 – P4 DTS Therm Mgn)
Processor DTS Thermal Margin
Sensors
Not applicable
87h
Processor 2 MSID Mismatch
(P2 MSID Mismatch)
Processor MSID Mismatch
Sensor
Processor MSID Mismatch Sensor – Next Steps
88h
Processor 3 MSID Mismatch
(P3 MSID Mismatch)
Processor MSID Mismatch
Sensor
Processor MSID Mismatch Sensor – Next Steps
89h
Processor 4 MSID Mismatch
(P4 MSID Mismatch)
Processor MSID Mismatch
Sensor
Processor MSID Mismatch Sensor – Next Steps
90h
Processor 1 VRD Temp
(P1 VRD Hot)
Discrete Thermal Sensors
Table 45: Discrete Thermal Sensors – Next Steps
91h
Processor 2 VRD Temp
(P2 VRD Hot)
Discrete Thermal Sensors
Table 45: Discrete Thermal Sensors – Next Steps
92h
Processor 3 VRD Temp
(P3 VRD Hot)
Discrete Thermal Sensors
Table 45: Discrete Thermal Sensors – Next Steps
93h
Processor 4 VRD Temp
(P4 VRD Hot)
Discrete Thermal Sensors
Table 45: Discrete Thermal Sensors – Next Steps
