4.7.3.2 Drive Bay Module #3 – NVMe* Cable Guide
The following table identifies the appropriate PCIe NVMe data cable kit(s) necessary to route PCIe signals from any of the onboard PCIe OCuLink
connectors and/or PCIe switch add-in card options to the 8 x 2.5” combo backplane installed to Drive Bay Module #3.
Select the cable kit or kits required to support the specific PCIe source or sources and the appropriate number of NVMe drives being installed to Drive
Bay Module #3 only.
Note: CR and CV refer to the connector types at each end of the PCIe OCuLink cable. See Table 9.
Table 64. Drive bay module #3 NVMe* cable guide
System
NVMe Drive
Drive Bay Module (BP) #3
PCIe Switch Card
PCIe Switch Card
Option on Riser #3
1
Drive Bay Module (BP) #3
Cable
Drive Bay #3
R2224WF…
Up to Eight
2.5” NVMe
SSDs
800mm – AXXCBL800CVCR
PCIe SSD 1 (CR) BP 1 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 2 (CR) BP 2 (CV)
600mm – AXXCBL600CVCR
PCIe SSD 3 (CR) BP 3 (CV)
600mm – AXXCBL600CVCR
PCIe SSD 0 (CR) BP 4 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 1 (CR) BP 5 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 2 (CR) BP 6 (CV)
530mm – AXXCBL530CVCR
PCIe SSD 3 (CR) BP 7 (CV)
530mm – AXXCBL530CVCR
All cables routed Right
Add-in Card
AXXP3SWX08040
Or
Switch BP ports 4-7
Right
Add-in Card
AXXP3SWX08040
Or
Switch BP ports 4-7
Right
Add-in Card
AXXP3SWX08040
Or
Switch BP ports 4-7
Right
8-port PCIe Switch
Add-in Card
AXXP3SWX08080
any open PCIe slot
Cable 1
Switch BP ports 4-7
Cable 2
A2U8PSWCXCXK2
Right
Right
8-port PCIe Switch
Add-in Card
AXXP3SWX08080
any open PCIe slot
Cable 1
Switch BP ports 4-7
Cable 2
Right
Right
8-port PCIe Switch
Add-in Card
AXXP3SWX08080
PCIe slot #2
Cable 1
Switch BP ports 4-7
Cable 2
Right
Right
1
PCIe switch cards installed to Riser #3 cannot be supported at this time.
