Intel S2600WF Series User Manual

Intel® Server S2600WF Product Family Configuration Guide
22
Table 5. Intel® Server Board S2600WF product family features
Intel® Server Board Feature
S2600WFT(R)
S2600WF0(R)
S2600WFQ(R)
Processor
• (2) – LGA3647-0 (Socket P) processor sockets
• Supports (1) or (2) processors from the 1
st
or 2
nd
Gen Intel® Xeon® processor Scalable family (Platinum, Gold, Silver, and Bronze). Note: Previous
generation Intel® Xeon® processors are not supported.
• Maximum supported Thermal Design Power (TDP) of up to 205 W (board only)
Note: Intel® Server Systems based on this server board family may support a lower maximum Thermal Design Power (TDP). See the appropriate
Intel® System TPS for maximum supported TDP.
Memory
• (24) – total DIMM slots (12 per processor)
o (6) – memory channels per processor
o (2) – DIMMs per channel
• DDR4 Registered DIMM (RDIMM) and Load Reduced DIMM (LRDIMM), up to 2933 MT/s (dependent on processor), 1.2 V
• DDR4-compatible Intel® Optane™ DC persistent memory module, up to 2666 MT/s, 1.2 V
1
Intel® C62x Series Chipset
Intel® C624 Chipset
Intel® C624 Chipset
Intel® C628 Chipset
Intel® QAT
No
No
Supported
Intel® Omni-Path Fabric
Supported
Supported
Supported
Onboard LAN
Dual Port RJ45 10 GbE
No
No
OCP* Module
Support
• Dual Port 10Gb RJ45 –
iPC 557T2OCPG1P5
• Dual Port SFP+ – iPC 527DA2OCPG1P5
• Quad Port 1Gb RJ45 – iPC I357T4OCPG1P5
• Quad Port SFP+ – iPC X527DA4OCPG1P5
• Dual Port 10Gb RJ45 – iPC X557T2OCPG1P5
•
Dual Port SFP+ – iPC X527DA2OCPG1P5
• Quad Port 1Gb RJ45 – iPC I357T4OCPG1P5
• Quad Port SFP+ – iPC X527DA4OCPG1P5
• Dual Port 10Gb RJ45 – iPC X557T2OCPG1P5
•
Dual Port SFP+ – iPC X527DA2OCPG1P5
Intel® Integrated SAS Module
Supported
Supported
Supported
Onboard PCIe* NVMe*
• (4) – OCuLink connectors
• Intel® VMD support
• Intel® RSTe/Intel® VROC support
(accessory option)
• (4) – OCuLink connectors
• Intel® VMD support
• Intel® RSTe/Intel® VROC support (accessory
option)
• (2) – OCuLink connectors
• Intel® VMD support
• Intel® RSTe/Intel® VROC support (accessory
option)
Onboard SATA
• (12) – SATA 6 Gbps ports (6 Gb/s, 3 Gb/s and 1.5 Gb/s transfer rates supported)
o (2) – single port 7-pin SATA connectors
o (2) – M.2 connectors – SATA/PCIe*
o (2) – 4-port mini-SAS HD (SFF-8643) connectors
• Embedded SATA Software RAID
o Intel® RSTe 5.0
o Intel® Embedded Server RAID Technology 2 1.60 with optional RAID 5 key support
• (4) – SATA 6 Gbps ports (6 Gb/s, 3 Gb/s and
1.5 Gb/s transfer rates supported)
o (2) – single port 7-pin SATA connectors
o (2) – M.2 connectors – SATA/PCIe*
• Embedded SATA Software RAID
o Intel® RSTe 5.0
Note: 4-port mini-SAS HD connectors are
present on S2600WFQ but are not configured as
SATA; these cables are used only for Intel® QAT.
Riser Card
Concurrent support for up to three riser cards
• Riser #1 – PCIe* 3.0 x24 (CPU1 x16, CPU2 x8) – 2 and 3 slot riser card options available
• Riser #2 – PCIe* 3.0 x24 (CPU2 x24) – 2 and 3 slot riser card options available
•
Riser #3 (2U systems only) – PCIe* 3.0 (CPU 2 x12) – 2 slot riser card available

Intel S2600WF Series Specifications

General

Form Factor	2U rackmount
Memory Support	DDR4 ECC Registered DIMMs
Chipset	Intel C621
Storage Options	SATA, SAS, NVMe (depending on the specific model)
Management	Intel Node Manager
Product Type	Server Motherboard / System
CPU Socket Type	LGA 3647
Memory Type	DDR4 ECC Registered
Storage Controllers	Intel VROC
SATA Ports	10 SATA3 ports
Network Controller	Intel i350-AM4
Expansion Slots	7 x PCIe 3.0 slots (x16, x8, x4)
SAS Ports	Support through optional add-on cards
