Intel® Server S2600WF Product Family Configuration Guide
23
Intel® Server Board Feature
S2600WFT(R)
S2600WF0(R)
S2600WFQ(R)
Video
•
Integrated 2D video controller
• 16MB of DDR4 video memory
• (1) – DB-15 external connector
• (1) – 14-pin internal connector for optional front panel video support
USB
• (3) – external USB 3.0 ports
• (1) – internal type-A USB 2.0 port
• (1) – internal 20-pin connector for optional 2x USB 3.0 port front panel support
•
(1) – internal 10-pin connector for optional 2x USB 2.0 port front panel support
Serial Port
• (1) – external RJ-45 serial-A port connector
• (1) – internal DH-10 serial-B port header for optional front or rear serial port support
Server Management
• Integrated baseboard management controller, IPMI 2.0 compliant
• Support for Intel® Server Management software
• Dedicated onboard RJ45 management port
• Advanced server management via Intel® RMM4 Lite – iPC AXXRMM4LITE2 (accessory option)
Security
• Trusted platform module 2.0 (Rest of World) – iPC AXXTPMENC8 (accessory option)
• Trusted platform module 2.0 (China Version) – iPC AXXTPMCHNE8 (accessory option)
System Fan
• (6) – system fans supported in two different connector formats: hot swap (2U) and cabled (1U)
o (6) – 10-pin managed system fan headers (sys_fan 1-6) – used for 1U system configuration
o (6) – 6-pin hot swap capable managed system fan connectors (sys_fan 1-6) – used for 2U system configuration
1 Intel® Optane™ persistent memory module is supported only by Intel® Server Boards S2600WFTR, S2600WF0R, and S2600WFQR with 2
nd
Gen Intel® Xeon® Scalable processor.

Intel S2600WF Series Specifications

General

Form Factor	2U rackmount
Memory Support	DDR4 ECC Registered DIMMs
Chipset	Intel C621
Storage Options	SATA, SAS, NVMe (depending on the specific model)
Management	Intel Node Manager
Product Type	Server Motherboard / System
CPU Socket Type	LGA 3647
Memory Type	DDR4 ECC Registered
Storage Controllers	Intel VROC
SATA Ports	10 SATA3 ports
Network Controller	Intel i350-AM4
Expansion Slots	7 x PCIe 3.0 slots (x16, x8, x4)
SAS Ports	Support through optional add-on cards
