Intel® Server S2600WF Product Family Configuration Guide
37
Table 9. Intel® Server System R2000WFTF product family features table
Intel® Server Board S2600WFTF product family
Maximum Supported Processor Thermal
Design Power (TDP)
o Front and back (non-storage system configurations only)
• RJ-45 serial port A connector
• Dual RJ-45 network interface connectors (S2600WFT-based systems only)
• Dedicated RJ-45 server management NIC
• (3) – USB 3.0 connectors on back panel
• (2) – USB 3.0 connectors on front panel (non-storage system configurations only)
•
(1) – USB 2.0 connector on rack handle (storage configurations only)
Internal I/O Connectors/Headers
• (1) – Type-A USB 2.0 connector
•
(1) – DH-10 serial port B connector
• (6) – managed 60 mm hot swap capable system fans
• Integrated fans included with each installed power supply module
Support for three riser cards:
• Riser #1 – PCIe* 3.0 x24 – up to 3 PCIe slots
• Riser #2 – PCIe* 3.0 x24 – up to 3 PCIe slots
• Riser #3 – PCIe* 3.0 x16 – up to 2 PCIe slots – Low profile cards only (optional)
With three riser cards installed, up to eight possible add-in cards can be supported:
• (4) full height/half-length + (2) full height/half-length add-in cards via Risers #1 and #2
•
(2) low profile add in cards via riser #3 (option)
The server system can have up to two power supply modules installed, providing support for the following power configurations:
1+0, 1+1 redundant power, and 2+0 combined power.
(1) power supply option:
•
Intel® Remote Management Module 4 (Intel® RMM4) Lite activation key
