3. Server System Configurations
The Intel® Server S2600WF product family includes several integrated server system options that include a 1U or 2U chassis with different hot swap
drive bay configurations, a specific server board, power supply module, and riser cards. At a minimum, building a functional server from one of these
options requires the following:
• Rack mount kit – rails or fixed mount
• Power cord(s)
•
Processor(s)
•
Memory
•
Storage drives
Figure 23. Intel® Server System options
Also offered are preconfigured L9 systems that require only the addition of power cords and storage devices to become a functional server. L9
systems are a part of the Intel® Data Center Block with Firmware Resilience product.
Optional Intel accessories that can be added include:
• Second power supply module to add power redundancy
• Intel® RAID support – PCIe* add-in card or module and appropriate SAS data cable(s)
• Intel® RAID Maintenance Free Backup unit – Intel RAID backup accessory
• Intel® Ethernet Network Adapter for OCP* - to add additional features without losing a PCIe add-in slot
• Intel® Remote Management Module Lite key – to add advanced server management features
See Chapters 5 and 6 for a full list of available options.
Intel® Server System R2000WF product family
(R2312WFxxxx shown)
Intel® Server System R1000WF product family
(R1208WFxxxx shown)
