Intel® Server S2600WF Product Family Configuration Guide
139
2U drive upgrade kit
1U/2U spares kit
This kit includes (3) different rack handles, including:
• (1) – Set of 2U storage rack handles with control panel and USB support
(R2312WFxxxx and R2224WFxxxx)
• (1) – Set of 2U non –storage rack handles (R2208WFxxxx and R2208WFxxxx + 8
Drive Accessory Kit)
• (1) – Set of 1U rack handles (R1304WFxxxx and R1208WFxxxx
This kit includes replacement chassis handles for all product family 1U and 2U systems.
In addition, this kit must be purchased for 2U building block configurations consisting
of 24x2.5” drives (3 drive bay modules) or when upgrading a R2208WF or R2208WF + 8
Drive Accessory Kit system to a 24 drive R2224WF system, where the standard chassis
rack handles must be replaced with a pair of storage rack handles that include the
system front panel and front USB 2.0 port.
See the appropriate Intel® Server System Product Family System Integration and Service
Guide for complete system integration, upgrade, and part replacement instructions.
Note: The 2U storage rack handles are not supported on R2312WFTF systems.
2.5” Tool Less Hot Swap Drive Carrier
Spare 2.5” tool less drive hot swap carrier
3.5” Tool Less Hot Swap Drive Carrier
Spare 3.5” tool less drive hot swap drive carrier
Includes mounting screws for mounting 2.5” SSDs.
Spare optical disk drive data cable for rack chassis famiy, 880 mm long.
Included with optical drives AXXSATADVDROM and AXXSATADVDRWROM.
