Auto LNB Skew Angle Adjustment for i6P/i6PE
The Intellian i6P/i6PE has an embedded auto skew angle control
system. Therefore, manual adjustment of skew angle by user is not
required. The skew angle is continuously adjusted automatically through
the calculation of the optimum skew angle by using the information of
the targeted satellite and the output value from the GPS sensor. Together
with such location information of the ship as ship’s longitudinal and
latitudinal position change from movement, the skew angle will be
adjusted accordingly. The skew angle of LNB is shown from the ACU and
GUI Program.
Figure 21 : Auto LNB Skew Angle Adjustment
Skew sensor
Skew motor
LNB
