Normal Mode
Start Up
With the system installed and power applied, the ACU screen will show
the following sequence:
1. Data communication is being established
between the antenna and the ACU. The ACU
is initialized.
2. The antenna is initialized.
3. The antenna is searching for Satellite A.
4. The antenna has located the satellite and is
now tracking.
INITIALIZE ACU
INITIALIZE ANTENNA
SEARCH A: DTV101
TRACKING A: DTV101
INTELLIAN i6
INTELLIAN i6
B:DTV119 SETUP
B:DTV119 SETUP
Changing Target Satellite
Your antenna is pre-programmed with either two (Dual-Sat mode) or
three (Tri-Sat mode) candidates of target satellites as a default mode.
To change a target satellite, press LEFT soft key. The target satellite is
changed and is automatically tracked by the antenna.
Default Dual-Sat Mode
1. Press LEFT soft key for tracking
Satellite B.
2. The antenna is tracking Satellite B.
TRACKING A: DTV101
TRACKING B: DTV119
B: DTV119 SETUP
A: DTV101 SETUP
To Next Page
