Intellian i6 Installation And Operation User Guide

57
Command Buttons
•EditSatelliteInformation–Tochangefrequencyinformationoftheantenna.
•SatelliteInformation–Satelliteinformationconsistsoffrequency,symboland
NID (Network ID) of a transponder in tracking satellite. There are four groups of
satellite information. ‘Vertical/RHCP’ is applied when IRD supply 13V, and
‘Horizontal/LHCP’ is applied when IRD supply 18V. ‘LOW’ is applied when DiSEqC
signal is not detected from IRD, ‘HIGH’ is applied when DiSEqC signal is detected
from IRD. If you select ‘Not Use’ or ‘Change Satellite’, two ‘HIGH’ groups are
inactivated. If you select Change Band’, two ‘High’ groups are activated and you
can modify satellite information which is applied when DiSEqC signal is detected
from IRD. After modifying information, press ‘Edit Satellite Information’ button, then
new information is updated in the antenna.
•Pol&BandControl–The“Pol”controls13V(Vertical/RHCPband)and18V
(Horizontal/LHCP band). The “Band” control DiSEqC 0KHz tone (Low band) and
22KHz (High band).
Set Tracking Information of Satellite [Primary]
The Antenna makes use of GPS information to search satellite signal faster.
The more precise the GPS information is, the quicker the antenna is able
to search for the satellite. The method to input information is to push “Set
GPS” button after keying in the latitude and longitude information on “City
GPS”. Pushing “Add City” button stores the GPS information. By selecting
the stored region in the list box, the GPS information of each region is
displayed. The Intellian i6/i6P/i6PE satellite TV antenna systems utilizes
GPS data to locate the satellite faster.
Figure 31 : Primary Tracking Information
