Intellian Satellite TV Antenna Systems
Function*
CHANGE SAT - Change the target satellite.
SLEEP MODE - Enter sleep mode.
CLEAR REGISTERED KEY - Clear registered key.
9. REMOTE KEY REGISTED will be displayed if key
has been properly registered.
REMOTE KEY REGISTED
FUNC : CHANGE SAT
NEXT EXITSELECT

Table of Contents

Other manuals for Intellian i6P

Preview: Quick Installation Guide
Quick Installation Guide3 pages
Preview: Installation And Operation User Guide
Installation And Operation User Guide67 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intellian i6P and is the answer not in the manual?

Intellian i6P Specifications

Operating Environment IconOperating Environment
operating temperature range-25°C to +55°C
storage temperature range-40°C to +80°C
humidity limit95% R.H
Antenna System Performance IconAntenna System Performance
frequencyKu-band (10.7 to 12.75 GHz)
minimum EIRP46 dBW
azimuth range680°
elevation range-5° to +90°
roll±25°
pitch±15°
roll and pitch response rate45° per second
turn rate45° per second
Power IconPower
power requirements9~30 V DC
power consumption typical30W
power consumption maximum50W
Weight and Dimensions IconWeight and Dimensions
satellite antenna unit dimensions70 cm x 72 cm
antenna dish diameter60 cm
antenna control unit dimensions17.8 cm x 21.7 cm x 5.4 cm
satellite antenna unit weight21 kg
antenna control unit weight1.2 kg
