Specification
105
9.2 RF Specification
Item Ku-band
Rx Frequency 10.7 ~ 12.7 GHz
Rx Gain (Without Radome) 32.0dBi
G/T 9.3 dB/K
Tx Frequency 14.0 ~ 14.5 GHz
Tx Gain (Without Radome) 35.0dBi
EIRP 33.6 dBW / 20 MHz (single carrier)
Cross pol Isolation Min 15 dB (Antennas Field of view)
Polarization Rx: RHCP, Tx: LHCP
9.3 Packing Specification
Item Specification
Antenna Package
Size 1010 mm x 1120 mm x 1126 mm
Weight 106 kg (233.7 lbs)
Material Paper+Wooden
CNX Package
Size 576 mm x 381 mm x 140 mm
Weight 6.3 kg (2.6 lbs)
Material Paper
Unit: mm
1010
1120
1126
381
140
576
9.4 Customer Network Exchange (CNX) Specification
Item Specification
Size (W x D x H) 442 mm x 249 mm x 40.4 mm (17.4" x 9.8" x 1.6")
Weight 5.1kg (11.2 lbs)
Antenna Subsystem Interface Eight GigE RJ-45 Ethernet(1 Management Port)
Encryption
MoCA 2.0
E-band (400-700MHz)
AC Input Voltage AC 100V ~ 240V/50Hz ~ 60Hz
Operating Power Max. 30 W
DC output range DC 56V +/- 5%
