Intellian v100GX User Manual

v100GX – Marine Satellite Communication System
16
Contains the items required for securing the antenna unit and ACU to the vessel.
Antenna Q’ty Description Size Remark
5
Hex. Bolt M12 x 80L
Antenna-Deck
4 Sets: Installation
1 Set: Spare
5
Flat Washer M12
5
Spring Washer M12
10
Hex. Nut M12
5
Hex Head
Wrench Bolt
M6 x 40L
Radome
(Spare Blots)
5
Dome Washer M6
ACU Q’ty Description Size Remark
5
Self-Tapping
Screw
M4 x 16
Table Mount
Bracket
10
Flat Head Screw M4 x 12L
Rack Mount
Bracket ACU
5
Sems Bolt M3 x 12L
Table Mount
Bracket ACU
Other Components
Installation Kit
Item Image Q’ty Description Size Remark
1
2
ACU
Bracket
Rack - ACU-19inch Rack
2 Table - ACU-Table
2 1 RG6 Cable 3m ACU to Modem
