OPERATING THE ACU

Set LNB Local Oscillator Frequency

System Settings

System menu

Set local frequency menu

LNB info

Setup mode

Save

SETUP MODE ?

YES NO

1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.

+ANTENNA +SATELLITE

+SYSTEM +INSTALLATION

2. Touch DOWN arrow key to move cursor to SYSTEM and touch OK key to enter it.

+SET LOCAL +SET LOCATION

+MODEM PORT +MANAGEMENT

3. Touch OK key to enter SET LOCAL menu to set the LNB local frequency.

13V + 0KHZ 18V + 0KHZ

10000MHZ 11300MHZ

13V + 22KHZ 18V + 22KHZ

10750MHZ

09750MHZ

4. Set LNB local oscillator frequency for each correspondent voltage power.

(13V +0 kHz, 18V +0 kHz, 13V +22 kHz, 18V +22 kHz)

Touch BACK key and Touch LEFT and RIGHT arrow keys to select the parameter you wish to

edit. Touch OK key to edit parameter. Or touch BACK key again to return to the main display.

LNB LOCAL: The selectable LNB frequencies are depended on the installed LNB type.

SAVE ?

YES NO

5. Touch LEFT arrow key to move cursor to YES and touch OK key to save current settings.

Or move cursor to NO and touch OK key to abort and return to the main display.
