v100GX – Marine Satellite Communication System

Setup Antenna LNB pol Angle

LNB pol angle type

Setup mode

Set pol angle menu

Antenna menu

LNB pol angle Signal

SETUP MODE ?

YES NO

1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.

+ANTENNA +SATELLITE

+SYSTEM +INSTALLATION

2. Touch OK key to enter ANTENNA menu.

+MANUAL SEARCH +SET POL ANGLE

+SEARCH PARAM +SET PARAMETERS

3. Touch RIGHT arrow key to move cursor to SET POL ANGLE menu and touch OK key to

enter it.

SELECT LNB POL. ANGLE MENU

C A L I B R A T I O N

4. Touch UP and DOWN arrow keys to select the LNB pol angle menu and touch OK key to

run the selected operation 'CALIBRATION' or 'MANUAL ADJUST'. Select MANUAL ADJUST

to control LNB pol angle manually. If the control board, LNB pol potentiometer or belt is

replaced, select CALIBRATION to calibrate LNB pol angle.

LNB POL ANGLE SIGNAL: 180

2 0

5. Touch UP and DOWN arrow keys to increase or decrease the LNB pol angle manually and

the correspondent SIGNAL level will be displayed next to it. Touch BACK key to return to the

main display.

NOTE: LNB POL ANGLE menu will be displayed only if MANUAL ADJUST is selected.
