OPERATING THE ACU

Set NBD tracking

frequency

Save

Set DVB tracking

frequency

DVB FREQ. SYMBOL NID

1 1 7 4 7 M H Z 21300kS ps 0X00AD

9. Set DVB FREQUENCY, SYMBOL RATE and NID when DVB mode of TRACKING SIGNAL

is chosen to be used.

45,000 is the maximum allowed symbol rate value. NID (network ID) range is from 0 x 0000

to 0 x FFFF (hexadecimal digit).

Touch LEFT and RIGHT arrow keys until the desired character is underscored (selected).

Touch UP and DOWN arrow keys to increase or decrease the value.

Or touch NUMBER keys to set the desired value directly.

Touch OK key to set the parameter.

NBD FREQ. BANDWIDTH

1070.000MHZ 01000KHZ

10. Set NBD IF FREQUENCY and BANDWIDTH when NBD (Narrow Band Detection) mode of

TRACKING SIGNAL is chosen to be used.

Touch LEFT and RIGHT arrow keys until the desired character is underscored (selected).

Touch UP and DOWN arrow keys to increase or decrease the value.

Or touch NUMBER keys to set the desired value directly. Touch OK key to set the parameter.

SAVE ?

YES NO

11. Touch LEFT arrow key to move cursor to YES and touch OK key to save and execute the

current settings. Or touch RIGHT arrow key to move cursor to NO and touch OK key to abort

and return to the main display.
