79
OPERATING THE ACU
SELECT PROCESS TYPE
B A C K U P U S E R D A T A
4. Touch UP and DOWN arrow keys to SELECT PROCESS TYPE*
Touch OK key to set the parameter and the processing message will be displayed.
SELECT PROCESS TYPE*
BACKUP USER DATA: To backup the antenna settings set by user to the ACU.
RESTORE USER DATA: To restore the antenna by using the backup user data stored from the ACU.
USE BLUETOOTH: To use bluetooth. If the select process type is set to "Bluetooth", the
data communication between Antenna and ACU will be disconnected. Refer to page 145 for
setting up bluetooth connection.
DEFAULT ACU-REMOTE P/W: to default ID and Password of the Web Server.
UPGRADE FROM USB: to upgrade the system by using the rmware les from a specied folder
in the USB ash drive.
COPY LOG TO USB: to copy the antenna log data from the system to the USB ash drive.
BACKUP TO USB: To backup the antenna settings to a specied folder in the USB ash drive.
RESTORE FROM USB: To restore the antenna by using the backup user data from a specied
folder in the USB ash drive.
UPGRADE ACU-REMOTE: To upgrade the system using the Remote Access rmware le
(ETSW-fs-XXX.bin) from a specied folder in the USB ash drive.
NOTE: UPGRADE FROM USB, COPY LOG TO USB, BACKUP TO USB, RESTORE
FROM USB and UPGRADE ACU-REMOTE options are displayed only if the USB ash
drive is plugged into the USB port located in the front panel of the ACU.
Management
System menu
Backup and restore
menu
Setup mode
SETUP MODE ?
YES NO
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Touch DOWN arrow key to move cursor to SYSTEM menu and touch OK key to enter it.
+SET LOCAL +SET LOCATION
+MODEM PORT +MANAGEMENT
3. Touch arrow keys to move cursor to MANAGEMENT menu and touch OK key to enter it.
Select process type
Processing
BACK UP ANT INFO
DO NO T TURN OFF!
To Next Page
