V110 – Marine Satellite Communication System
Setting Antenna Search Parameter
These parameters should only be changed by an authorized service
technician. Improper setting of these parameters will cause your system
to perform improperly.
3. Press DOWN arrow keys to move cursor to SEARH PARAM and press OK key to
enter SEARCH PARAM menu.Press the LEFT and RIGHT arrow keys to select the
parameter you wish to edit. Press OK key to edit parameter. Or press RETURN key
again to return to the main display.
◀ +MANUAL SEARCH +SET SKEW ▶
→+SEARCH PARAM +SET PARAMETERS
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Cont rol Unit
SETUP MODE ?
→ YES NO
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Cont rol Unit
1. Press LEFT key to move cursor to YES and press OK key to enter setup mode.
→+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Cont rol Unit
2. Press OK key to enter ANTENNA menu.
OK
M
R
F
OK
M
R
F
OK
M
R
F
SEARCH WAIT TIME INCREMENT STEP
▲ 0
30 ▼ 0.80
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Cont rol Unit
4. Set SEARCH WAIT TIME and INCREMENT STEP
Set the time-out for automatic initiation of a search after the signal level drops below
the pre-defined threshold value (Range : 1 - 120 sec) and set increment step size.
(Range : 0.01 – 5.00 sec)
Press LEFT and RIGHT arrow keys until the desired character is underscored
(selected). Press UP and DOWN arrow keys to increase and decrease the selected
character. Or press NUMBER keys to set the desired value directly. Press OK key to
set the parameter and set next parameter. Press RETURN key to select the parameter
you wish to edit and press RETURN key again to save or abort and return to the main
display. .
OK
M
R
F
To Next Page
