DVB VERIFY SKEW OFFSET
▲ DVB DECODE ▼ +0.0
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
6. Edit the satellite DVB VERIFY and SKEW OFFSET.
DVB VERIFY will be only activated and applied when choose to use DVB on tracking
signal . Press UP and DOWN arrow keys to select DVB Verify 1) and press OK
key to set the parameter.
SELECT LOCAL TRACKING SIGNAL
▲ 1
1300MHz ▼ NBD
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
7. Set th e LNB LOCAL frequency and TRACKING SIGNAL1) .
Press LEFT and RIGHT arrow keys until the desired character is underscored
(selected). Press UP and DOWN arrow keys to increase or decrease the value.
Or press NUMBER keys to set the desired value directly. Press OK key to set th e
parameter.
Tracking Signal 1)
-NBD
-DVB
DVB Verify 1)
- AGC – use signal level for satellite tracking.
- DVB Lock – use DVB Lock for satellite tracking.
- DVB Decode – use DVB Decode for satellite tracking.
- DSS Decode – use DSS Decode for satellite tracking.
RX POL TX POL
▲ VERT. ▼ HORI.
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
8. Set the RX POL and TX POL
To select the polarity for both RX (receive ) and TX (tran smit ) pol.
Press UP and DOWN arrow keys to select VERTICALor HORIZONTAL . Press OK
key to set the parameter.
OK
M
R
F
