Intellian v60E User Manual

20
v60E - Maritime VSAT Antenna System
Unit: mm (inch)
Option 1. When Installing Cable Through Inside Mast
Figure 9: Recommended Size of Mast (Option 1)
BOW
247.5 (9.74)
247.5 (9.74)
4 - Ø15.0 (0.59) Hole
15˚
Ø110.0 (4.33)
Ø180.0 (7.09)
Ø200.0 (7.87)
Gooseneck
Ø445.0 (17.52)
Ø22.0
(0.87)
Ø200.0 (7.87)
800.0 (31.50)
200.0 (7.87)
1000.0 (39.37)
Plate Thickness
Min. 10.0 (0.39)
Max. 15.0 (0.59)
Ø45.0 (1.77)
Ø445.0 (17.52)
