Intellinet 525824 User Manual

- 6 -
CONNECTORS





Item Description
1 FemaleRP‐SMAconnectorsfortheconnectionofthe externalhigh‐gainantennas(included). Besure
tomatchup2.4and5GHz
2 Resetbutton.Depressfor10secondstoinitiatearesettofactorydefaultvalues.
3 WAN/LANconnectorandpassive‐PoEinputport.
4 Groundconnector.

PASSIVE‐POEINJECTOR
TheIntellinetAccessPointcomeswithaPassive‐PoEInjectorthatallowsyoutomergepoweranddatatooneEthernet
cableandsupplythemtotheaccesspoint.Ithasthreeconnectionpoints:apowerinputportfortheexternal24VDC
poweradapter(2),aLANportfortheconnectiontoyourlocalnetwork(1),andaPoEportfortheconnectiontothe
accesspoint’sLANport(4).Thepowerbutton(3)doeswhatyouthinkitdoes.

 






