EncoreCX
Installation & Maintenance Manual
34
Attaching the digital telephone desk pedestal (ECX 1000/ECX 1000W and ECX 2000)
Position at 35 degrees Position at 20 degrees
Wall mount Plinth
p
osition
Pedestal position 20 °
Pedestal position 35°
Text port only. No user functionality
