EncoreCX
Installation and Maintenance Manual
59
Call recalling 1s on 400 ms off,
400 ms on 1.2 s off
Tone frequencies 440 Hz ±5 Hz, unless stated otherwise
Tone cadences
Dial Tone Continuous tone of 440 Hz ±5%
and 350 Hz ±5% combined
Special dial tone 800 ms on 800 ms off of 440 Hz ±5%
and 350 Hz ±5% combined
Ringback tone 1 sec on 2 sec off
Busy tone 500 ms on 500 ms off
Congestion tone 200 ms on 200 ms off
Hold tone200 ms on 200 ms off,
200 ms on 3.4 s off
Conference tone One burst of 400 ms
NU tone Continuous tone
Call waiting tone 100 ms on 4.9 s off
Environmental requirements
Normal working temperature 0°C to 40°C
Storage temperature -40
°C to +85°C
Working humidity (non-condensing) 5% to 95%
Storage humidity 5% to 95% @60
°C
Doorstrike relay contact
Max rating 24 Volts DC
2 Amps
Door Phone Size
Height 8 inches (203 mm)
Width 2.9 inches (73 mm)
Depth 1.5 inches (38 mm)
Color of System Charcoal ref: Pantone 432C
Internet Router Module Info
LAN 4 x 10/100 Base-Tx Extension
DSL 10 Base-T output for an external DSL modem
ISDN Access to B-channels on PABX PPP, MLPPP, BACP
Protocols IP V4
Authentication PAP/CHAP
DHCP DHCP server supports up to 100 IP addresses
Routing Static routing
Firewall NAT, Packet filtering
Call management Idle timers
Time of day restriction
Management Local management
Remote management
Installation Wizard
