Handling the Base Unit
WARNING Do not use the bottom portion of the face panel or the lip at the top rear of the base
unit as a hand hold when moving the base unit. Equipment damage and personal
injury can result.
Do not lift
here!
Do not lift
here!
Opening and Closing the Door
Open the door on the system’s front panel to gain access to the Standby button, the floppy
disk drive, the CD-ROM drive, and any optional peripheral device installed in the external
device bay. You can use your system with the door open or closed. See the following figure
for more details.
To open and stow the door:
1. Grasp the lip at the bottom of the door and lift up until the door is even with the top of
the unit.
2. Push the door into the case until the door stops.
