Installation Guide 51
Operating temperature
-10 to +50 °C (14 to 122 °F)
Dimensions
Flush: 246 × 245 mm
(9.69 × 9.65 in.)
Surface: 179.8 × 239 mm
(7.07 × 9.41 in.)
Weight
3 kg (6.61 Ib.)
Environmental rating
IP54, IK10
TruVision Pendant/Wall IR HD-TVI PTZ
Dome
Electrical
Voltage input
24 VAC
Power consumption
Max. 30 W
Miscellaneous
Connectors
24 VAC, HD-TVI Output, 960H
Analog Output
Operating temperature
-30 to +65 °C (-22 to +149°F)
Dimensions
220 × 353.4 mm
(8.66 × 13.91 in.)
Weight
4.5 kg (9.92 Ib.)
