Installation Guide 41
Flush mount the camera
Flush-mounting is suitable for indoor ceiling construction. The
following requirements are mandatory preconditions for
mounting:
The height of the space above the ceiling must be greater
than 250 mm (9.843 in).
The thickness of the ceiling must be between 5 and
40 mm (0.197 to 1.575 in).
The ceiling must be strong enough to withstand more
than four times the weight of the dome and its
accessories.
To mount the surface/flush HD-TVI PTZ dome flush with a
ceiling:
1. Rotate the lower dome counterclockwise to separate it
from the back box, as shown below.
To Next Page
