Intermec EasyCoder F2 – Installation & Operation Ed. 2100
Appendix 3 Interfaces
Industrial
Interface Board
The EasyCoder F2 can optionally be fitted with an Industrial
Interface Board, that provides the printer with one extra serial
communication port ("uart2:"), which can be confi gured for one
of the following alternatives
RS 232C
RS 422 Non-isolated
RS 422 Isolated
RS 485
This port is identical to "uart2:" on the double serial interface
board.
The Industrial Interface Board also has a female DB-44 connector
with...
8 digital IN ports with optocouplers
8 digital OUT ports with optocouplers
4 OUT ports with relays.
Refer to the installation instructions for the Industrial Interface
Board for further information.
"uart2:"
Industrial Interface
