Intermec EasyCoder F4 – Installation & Operation Ed. 3110
Appendix 3 Interfaces
Industrial
Interface Board
The EasyCoder F4 can optionally be fitted with an Industrial
Interface Board, which provides the printer with one extra serial
communication port ("uart2:"). This post can be confi gured for
one of these options:
RS-232
RS-422 Non-isolated
RS-422 Isolated
RS-485
This port is identical to "uart2:" on the double serial interface
board.
The Industrial Interface Board also has a DB-44pin female
connector with:
8 digital IN ports with optocouplers
8 digital OUT ports with optocouplers
4 OUT ports with relays
Refer to the installation instructions for the Industrial Interface
Board for further information.
"uart2:"
Industrial Interface
