10 Intermec EasyLAN Interface Kit Installation Instructions
Chapter 2 — Setup in Fingerprint
Reading or Setting the IP Address
• After having selected the method for assigning the IP address, the
display shows:
NETWORK:
IP ADDRESS
• If you have chosen either DHCP+BOOTP, DHCP, or BOOTP, press
the ↓ key and you can read the temporary IP address automatically
assigned by the server, for example:
IP ADDRESS:
192.168.1.79
• If you have selected MANUAL, the display will only show this (or
possibly an existing IP address):
IP ADDRESS:
0.0.0.0
• Before you can enter the IP address, you must fi rst the data on the
lower line by repeatedly pressing the C key. Then you can type the
desired IP address using the numeric keys on the printer’s keyboard.
• After having read or set the IP address, press the Enter key to go on to
Netmask parameter or press the Setup key to exit the Setup Mode.
Reading or Setting the Netmask, Default Router, and Name
Server
• These parameters work in the same way as reading or setting the IP
address. In case of DHCP, BOOTP, or DHCP+BOOTP, these para-
meters are set automatically by the server. In case of the MANUAL
method, you will have to set these parameters at least partly yourself
via the printer’s keyboard or via the printer’s home page. Refer to the
diagrams on the next page.
