Intermec EasyLAN Wireless—Interface Kit Installation Instructions 3
Chapter 1—Physical Installation
• Remove any optional interface board or blind cover plate fi tted on the
rear plate.
• Remove any present EasyLAN Ethernet interface installed in the
printer including cables etc.
• Remove the present rear plate like this:
- Loosen but do not remove the two #T20 Torx screws that hold
the rear plate and the #T20 Torx screw that holds the rear bottom
corner of the CPU board.
- Carefully manipulate the rear plate out of the groove in the chassis.
Allow the CPU board to fl ex a little to be able to get the connectors
out of their slots.
• Install the rear plate included in the kit in reverse order and tighten all
three screws.
• Reinstall any optional interface board or blind cover plate previously
removed.
• Continued on page 5.
