Interpump SS71 - 16 Exploded Drawing and Parts List

ENGLISH
34
16 EXPLODED DRAWING AND PARTS LIST
Fix with Loctite 243 color Blue Code 12006400
Power take-o with reduction gear OPTIONAL
Attention not available for ATEX version pumps
OPTIONAL
Drawbar and Joint for coupling to hydraulic motors SAE C
OPTIONAL
Auxiliary PTO on the side opposite of the drive
Fix with Loctite 243 color BLUE Code 12006400
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
Type "A" ange for direct drives
Seal Flushing System
Fix with Loctite 542 code 12006200 or Loxeal 53-14
System with NPT connections
Pre-tightening torque 10÷15 Nm
Lubricate the underhead with grease type: Molybdenum Disulphide code 12001500
Flange for direct coupling to hydraulic motors SAE C
Lubricate with silicone grease OCILS 250 code 12001600 on the external diameter only
