DriveControl DC-20/DC-54
Assembly
DriveControl 54 Required conductors:
 Prepare wire ends according to the recommendations of the contact
manufacturer.
 Unscrew the two yellow cover screws of the connection area.
 Open the cable bushings to the connection area according to the cables used.
 Route the cable through.
 Connect the conductors for inputs and outputs (for inputs and outputs see
"DriveControl 54", page 19). For this purpose push the white slide to the right
(in the direction of the cable bushes), insert the conductor and push the slide
back.
 Connect the conductors for operating voltage (for connections see
"DriveControl 54", page 19). For this purpose push the white button
downwards and insert the conductor.
 Enable cable strain relief.
 If necessary, set the DIP switches according to requirements (see
"Operation", page 24).
 Close the cover and fasten both screws.
 Visually inspect the connection area to ensure that IP54 protection exists.
 Insert the plug of the RollerDrive so that with the DriveControl the "RD"
labeling can be read and the "EC310" labeling is to the rear, i.e. cannot be
read.
Connection Conductor
Inputs/Output
s
fine-strand: 0.08 to 0.5 mm
2
(AWG 28 to 21)
fine-strand with end-splice: 0.25 mm
2
(AWG 24)
Stripped length: 5 to 6 mm (0.2 to 0.24 in)
Power supply fine-strand, H05(07) V-K: 1.5 mm
2
(AWG 16)
(optionally with end-splice according to DIN 46228/1)
AWG: 16
Stripped length: 8 mm (0.31 in)
