3.7 Programs
3.7.1 Create a program
In the main menu, choose the option “MODIFY PROGRAMS”. On the screen will appear the list of
the programs already created. If you scroll the list, at the end will appear a list of standard names:
program 5, program 6, etc… These are unused programs. If you want to create a new program for your
needs, use one of them.
Select it as indicated below and press on the rotating button. Please look at the next chapter 3.7.2
Modify a program. In this chapter you will learn how to rename a program and change parameters.
3.7.2 Modify a program
From the main menu, select “MODIFY PROGRAMS”. A screen displays the list of names of
programs already created. Select the program you want to edit and press on the rotating button.
The screen that appears shows under the name of the program, a list of all its parameters.
Example :
The list of parameters vary depending on how the program works : by dose or continuous. Here is the list
of all the parameters:
• Name of the program
• Distribution mode
• Pump speed
• Tubing inner diameter
• Power of pump motor
• Volume of a dose (unless the functionning mode is continuous)
and for the muti-dose only:
• Number of doses
• Delay in-between the doses
Please find later in the chapter, the meaning of each parameter and how to modify it. To generally
modify a parameter, turn the button to select the line where the parameter appears and press the button.
When you have finished modifying these parameters, turn the button until you select the word “S A V E ”
at the bottom of the screen and press on the button.
MODIFY PROGRAMS
Dish 18 ml
Multi 9ml
Continuous
program 5
program 6
NAME: program 5
MODE: doses
SPEED: 200 rpm
TUBE Ø: 3.2 mm
POWER: auto
VOLUME: 1.57 l
SAVE
NOM: program 5
MODE: doses
SPEED: 200 rpm
TUBE Ø: 3.2 mm
POWER: auto
VOLUME: 1.57 l
SAVE
