18
You can also press on the “esc.” button to come back to the main menu.
Rename a program
To change the name of a program, select the line “N A M E ” and press the rotating button. The cursor
place itself on the first letter. Select then with the rotating button the letter you wish to change and press
on the button.
Example to change from 9mL tubing to 18mL tubing:
Turn then the button to modify the character under the cursor. Typographic characters scroll: numbers
first and then alphabetic letters and punctuation characters. Turn the button until the character appears
under the cursor and press on the button to validate. The cursor then goes to the next letter.
Turn again the button to modify the next letter. Repeat the operation for all the letters you have to
change. For all the letters you do not want to change, when the cursor is on the letter, just press on the
button to validate. The cursor goes to the next letter. When you have chosen and validated the next
letter, press twice on “esc.”.
How to delete characters :
When the cursor is on a letter you wish to delete, in the case the name the new name is shorter than the
rpevious one, turn the rotating button to the left or to the right until the letter disappears. Press then on
the button to validate the suppression. The cursor then goes to the next position.
Repeat until everything is erased. When you have erased the last letter, press on « esc. » twice.
Distribution mode
Each program must have at least one dispensing mode : dose, multi-dose or continuous. (Cf. paragraph
3.1 Principles of use)
To change this mode, select the line “M O D E ” and press on the rotating button.
Then, by turning the button, make the display mode you want and validate by pressing the rotating
Turn the button to put the cursor on the number 9
and press on the button.
NOM: tube 9 ml
MODE: doses
SPEED: 200 rpm
TUBE Ø: 3.2 mm
POWER: auto
VOLUME: 1.57 l
SAVE
Turn then the button to make the numbers appear up
to number 1 and press on the button to validate.
The cursor will go to the letter m following the
number 1.
NAME: tube 1 ml
MODE: doses
SPEED: 200 rpm
TUBE Ø: 3.2 mm
POWER: auto
VOLUME: 1.57 l
SAVE
There is no more lettre to add: press
twice on the button esc. to end.
NAME:tube 18ml
MODE: doses
SPEED: 200 rpm
TUBE Ø: 3.2 mm
POWER: auto
VOLUME: 1.57 l
SAVE
