9
- RS232 thermal printer (ref. 521 000)
Available with FlexiPump
®
Pro, the RS232 printer connects with the RS232
port at the back of the unit.
All dispensing informationss are printed on a label.
2.2 Installation
To use FlexiPump
®
at its best, we suggest to install it on a stable, flat and rigid surface. Check that the
bottle is placed at the same level or lower than the FlexiPump
®
to avoid that the water flows after the
pumping is stopped. The bottle can be placed on the ground to save space.
Proceed as shown below:
- Put the tube into the peristaltic pump (from front to back). Be careful to center it to avoid to pinch the
tubing when closing the pump. (BE CAREFUL: carefully read the tubing installation guide provided).
When the pump is opened, you can adjust,
according to the inner diameter of the tubing,
by moving the rotating button.
1
Shut the top-shell of the pump.
NOT CORRECT
The tubing is pinched.
It can be perforated.
CORRECT
The tubing is not pinched.
It cannot be perforated.
3
4
Insert the tubing in the pump.
2
