Intertek FT Series - Page 87

The FT Series Floor Standing, Heating Only Boiler
Page 87
FTHF199
Tank and Water Pipe Parts
No. Description Laars
Part Number
29 DHW Water Tank Ass’y FT3132
30 Internal Circulation Pipe 2
Ass’y
FT3047
30-1 Internal Circulation Pipe 2
P-4 1” Packing FT1691
31 Boiler Pump Ass’Y FT3049
31-1 Boiler Pump
P-4 1” Packing FT1691
B-1 M4 x 10MM Pan Head Screw
(ne thread)
32 Pump Bottom Pipe Ass’y FT3051
32-1 Pump Bottom Pipe
P-4 1” Packing FT1691
33 CH Return Connection Ass’y FT3053
33-1 CH Return Connection
33-2 Ball Valve FT1708
33-3 Short brass tting FT3055
C-1 Piping Clip1 FT1107
O-24 O-Ring P24 FT3056
P-4 1” Packing FT1691
34 CH Return Pipe Ass’y FT3057
34-1 CH Return Pipe
C-1 Piping Clip1 FT1107
O-24 O-Ring P24 FT3056
P-4 1” Packing FT1691
35 CH Return Connection FT3059
36 CH Return Sensor FT1635
37 3way Connection Ass’y FT3060
37-1 3way Connection
P-1 3/8” Packing FT3062
P-4 1” Packing FT1691
O-24 O-Ring P24 FT3056
C-1 Piping Clip1 FT1107
C-2 Piping Clip2 FT1108
38 CH Supply Pipe Ass’y FT3063
38-1 CH Supply Pipe
P-4 1” Packing FT1691
O-24 O-Ring P24 FT3056
C-2 Piping Clip2 FT1108
39 CH Supply Connection FT3065
No. Description Laars
Part Number
40 Adapter Pipe Ass’y FT3066
40-1 Adapter Pipe
P-4 1” Packing FT1691
41 Adapter Connection FT3068
42 Internal Circulation Pipe 1
Ass’y
FT3069
42-1 Internal Circulation Pipe 1
P-4 1” Packing FT1691
B-10 M5 x 10MM Hex Head Screw
(ne thread)
