SAVE THESE INSTRUCTIONS
English
(329IO) MODEL ECO5220/5230 & 6220/6230 SALTWATER SYSTEM WITH E.C.O. ENGLISH 7.5” X 10.3” PANTONE 295U 05/23/2024
Page 20
SALTWATER SYSTEM STATIONARY MOUNTING
Some countries, especially in the European community, require the product to be
secured to the ground or to a base in a permanent upright position. Check with
your local authorities to determine if there is a regulation in your area regarding
above-the-ground swimming pool filter pumps. If yes, then the product can be
mounted to a platform using the two holes located in the base. See drawing
below.
The product can be mounted on a cement base or onto a wooden platform to
prevent accidental tipping. Total assembly must exceed 18kg.
1
.
For model ECO5220/5230:
The mounting holes are 6.4mm in diameter and
spaced 65mm apart.
For model ECO6220/6230:
The mounting holes are 6.4mm in diameter and
spaced 69mm apart.
2
. Use two bolts and lock nuts with a maximum of 6.4mm in diameter.
65mm
Model ECO5220/5230
69mm
Model ECO6220/6230
