4.2SafeAssembly
WARNING!
RiskofInjuryorDamage
Improperassemblymaycauseinjuryordamage.
Useofincorrectorimproperparts,including
replacement(service)parts,maycauseinjuryor
damage.
–AssemblyMUSTbeperformedonlybyqualied
personnel.
–UseonlyInvacarepartsintheassemblyofthis
patientlift.Thebase,legs,mast,boomand
hangerbararemanufacturedtospecications
thatassurecorrectalignmentofallpartsfor
safefunctionaloperation.
–ReplacementpartsMUSTmatchoriginal
Invacareparts.
–ALWAYSprovidetheliftserialnumbertoassist
inorderingthecorrectreplacementparts.
–DONOTovertightenthemountinghardware.
Thiswilldamagethemountingbracket.
RiskofInjuryorDamage
Thereisariskofsqueezingofbothlimbsand
wiresduringassemblyanddisassemblyofthelift.
–Activatetheemergencystopbeforeassemblyor
disassemblytoprevententrapment/squeezing.
–Taketheutmostcarewhenliftingcomponents
duringassembly.Somepartsareheavy.Always
remembertoadoptthecorrectliftingposition.
Thefollowingtoolsarerequiredtoassemblethe
patientlift:1/2”wrench(spanner)and3/16”Allen
key.
Ifthereareanyissuesorquestionsduringassembly,
contactalocalInvacarerepresentative.Refertothe
contactinformationinthebackofthismanual.
4.3AssemblingtheMasttotheBase
WARNING!
RiskofFire
Incorrectelectricalconnectionscancausere.
–Beforemakingelectricalconnections,inspect
connectorsfordamage.Ifdamageisfound,
contactanInvacaredealerorqualied
technicianforservice.
–Ensureelectricalconnectorsarecompletely
connected.
–Ensureelectricalconnectorsareconnectedto
thecorrectcomponents.
–DONOTforceconnectorstogether .If
connectionsarenoteasyandsmooth,verify
thecorrectcomponentsarebeingconnected.
ContactInvacare,adealeroraqualied
technicianforservice.
