8.8ReplacingtheHangerBar
Thisprocedureshouldonlybeperformedbya
qualiedtechnician.
CAUTION!
RiskofDamage
Themountingbracketcanbecomedamagedif
hardwareisovertightened.
–DONOTovertightenthenutandscrew.
1.RemovethesidecoversA.
SupportthehangerbarBfromunderneath
whileremovingtheattachinghardware.
2.RemovethescrewC,washersD,angedbearingsE,
nylonspacersFandnutGthatsecurethetopofthe
hangerbarpinHandtoprubbercapItotheboomJ.
3.RemovetherubbercapsK.
4.RemovethesocketscrewL,washersM,atwasherN
andnutOsecuringthebottomofthehangerbarpin
tothehangerbar .
5.Toinstallthehangerbar,reverseSTEPS1–4.
