5.7.3UsingtheBatteryChargertoChargetheBattery
REMOVINGFROMLIFT:
1.LiftuponthehandleAonthebackofthebatteryB.
2.LiftthebatteryupandoutawayfromthecontrolboxC.
CAUTION!
Mountingthebatteryimproperlymaycause
injuryordamage.
–Makesurethereisanaudibleclickwhen
mountingbatteryonthebatterychargerto
conrmpropermounting.
3.PlacethebatteryonthebatterychargerDasshown.
Makesurethereisanaudibleclick.
ThechargeLEDwillilluminate.Whenchargingis
complete,chargeLEDwillstopilluminating.
Abatteryneedingtobefullyrechargedwilltake
approximatelyfourhours.
REMOVINGFROMCHARGER:
1.Liftuponthehandleonthebackofthebattery.
2.Liftthebatteryupandoutawayfromthebattery
charger .
CAUTION!
Mountingthebatteryimproperlymaycause
injuryordamage.
–Makesurethereisanaudibleclickwhen
mountingbatteryonthecontrolboxtoconrm
propermounting.
3.Reinstallthebatteryontothecontrolboxasshown.
Makesurethereisanaudibleclick.
Thebatterymountstothecontrolboxandbattery
chargerasshown.
