Invacare®Jasmine™
1.Putthebaseonalevelsurfacesoallcastersmake
contactwiththeoor .
2.PressdownonthetabsAtolockrearcastersB.
3.UnscrewthetopknobCandremoveitfromthebase
D.
4.LoosenthebottomknobE,butleaveitscrewedinto
thebase.
5.Connectthemastassemblycable(notshown)tothe
basecable(notshown).
6.PositionthetubeofthemastassemblyFintothehole
inthebaseassembly.Makesurenottosqueezethe
cablesbetweenmastandbase.
7.Whilesupportingthemastassembly,tightenthebottom
knob.
8.Screwthetopknobintotheholeinthebase,ensuring
thetopknobistightened.
9.ReverseSTEPS2–8todisassemblethelift.
WARNING!
RiskofInjuryorDamage
Toavoidinjuryordamagefrominstabilityof
themast:
–DONOTremovetheplasticbushingin
thebasethatsurroundsthemastduring
disassembly.
4.4CheckingtheServiceLight
Eachtimetheliftisassembled,andbeforeusingthe
lift,theservicelightshouldbechecked.
1.Assemblethelift.
2.ExaminethecontrolboxAorthehandpendantBto
seeiftheservicelightCisashing.
3.Refertothetable.
ServiceLightInitialAssemblyReassembly
FlashingResetthe
servicelight.
Referto8.4
Resettingthe
ServiceLight,
page51.
Theliftrequires
service.Contact
yourlocal
Invacare
dealeror
representative
forservice.
NotFlashing
N/A
Theliftisready
foruse
