Invacare®Jasmine™
LiftType
Electric
Base
Electric
Highestposition(max.heightof
CSP*)(k)
212cm
Lowestposition(min.heightofCSP*)
(l)
74cm
Hoistingrange(m)
138cm
Liftingarea(heightrange)
54—192cm
Heighttoupperedgeoflegs(t)
12cm
Min.freeheight(s)
4,5cm
Minimuminternalwidth(r)
53cm
Internalwidthatmaximumreach(q)
103cm
Maximumlengthofthebase(u)
134cm
MaximumInternalLengthoftheBase
(v)
90,5cm
MaximumExternalWidthofLegs
Open(y)
128cm
Totalwidth(open)centretocentre
ofcastors(p)
122,5cm
MinimumInternalwidthoflegs
(open)(z)
118cm
MaximumExternalwidthoflegs
(closed)(w)
69cm
MinimumInternalwidthoflegs
(closed)(x)
56,5cm
Castorsize(FRONT/REAR)
10cm
Slingmaterialpolyester
Maximumpatientweightlimit
200kg(31stone)
Totalweight(weightoutofcarton)
43kg
Weight,mastincludingbatteryand
hangerbar
21,2kg
Weight,legsection21,8kg
Maximumreachat60cm(a)
60cm
Maximumreachfrombase(b)
66cm
Reachfrombasewithlegsspreadto
70cm(c)
24,5cm
OperatingforcesofbuttonsMax.
5N
Battery(voltageoutput)
24VDCmbMax.
240VA
ChargerInput(voltagesupply)
100-240VAC~
50/60Hz
ChargerOutput/ChargingTime
29.5VDC2.9Ah
Max6hrs
Audio/VisualLowBatteryAlarm
Yes
MotorSafetyDevices
Anti-Entrapment
Workingability
**40liftswithout
batterychargewith
batteriesat50%of
fullcapacity
Velocityofliftingandlowering
<0.15m/sunder
maximumloadand
<0.25m/sunloaded
Max.currentinput
Max.400mA
Standards
ISO10535:2006
DegreeofProtection***,lift
IP24
LiftActuator
IPX4
Controller
IPX4
Pendant
IPX4
